Pre fabricated shopping complex

Get a Price/Quote

Product Details:

Dimension (L*W*H) 36 ft x 20 ft x 10 ft (custom sizes available)
Door Material Steel with powder coating or insulated panel doors
Life Span 15-20 years
Insulation Polyurethane foam or Expanded polystyrene
Open Style Sliding, Hinged
Wall Materials Insulated sandwich panels (PUF/PIR/EPS)
Window Material Aluminum framed glass windows
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Pre fabricated shopping complex Price And Quantity

Minimum Order Quantity 1000 Square Foot

Pre fabricated shopping complex Product Specifications

Door Material Steel with powder coating or insulated panel doors
Roof Dead Load 20-40 kg/m2
Color Customizable, standard white/grey
Dimension (L*W*H) 36 ft x 20 ft x 10 ft (custom sizes available)
Door Single/Double leaf
Roof Material Pre-painted galvanized iron (PPGI) sheets
Open Style Sliding, Hinged
Use Shopping complex, Commercial spaces
Earthquake Intensity Designed for up to Zone IV
Roof Live Load 0.75 kN/m2
Floor Load Up to 300 kg/m2
Life Span 15-20 years
Connection Bolted and welded joints
Material Mild steel, Galvanized steel, Insulated panels
Window Material Aluminum framed glass windows
Window Fixed/Sliding
Thickness Of Wall Panel 50-100 mm
Insulation Polyurethane foam or Expanded polystyrene
Window Style Sliding type
Wall Materials Insulated sandwich panels (PUF/PIR/EPS)
Floor Material Anti-skid ceramic tiles over RCC or steel deck floor

Wind Resistance Designed up to 150 km/h
Finish Smooth exterior finish, powder coated surface
Relocation Fully relocatable and re-installable
Assembly Time 2-4 weeks depending on scale
Foundation Pre-cast concrete blocks or RCC plinth
Ventilation Forced ventilation/exhaust fans provisioned
Waterproofing Sealed joints and flashings for leak resistance
Lighting LED, energy-saving options available
Electrical Provision Ready for concealed wiring and fittings
Structural System Pre-engineered modular steel frame
Fire Resistance Wall panels fire rated up to 1 hour
Acoustic Property Panels with sound insulation up to 28 dB

Pre fabricated shopping complex Trade Information

Delivery Time 7 Days

Product Description

Introducing our Mild Steel Structural Sheds, expertly designed for factory use. These multi-span steel sheds are perfect for large-scale operations, offering robust durability and flexibility. Our pre-fabricated installation ensures quick setup, minimizing downtime. Available in a variety of vibrant colors, these sheds not only enhance functionality but also add aesthetic appeal to your workspace. With a minimum order range of 5,000 to 10,000 sqft, we cater to diverse industrial needs. Trust us for quality and reliability in your factory shed solutions! PEB structures are widely used across industrial, commercial, and institutional sectors due to their speed, strength, and cost efficiency. Industrial Applications Manufacturing units & factories Warehouses & logistics hubs Cold storage facilities Workshops & assembly plants Power plants & utility buildings Commercial Applications Prefabricated restaurants & food courts Shopping complexes & showrooms Office buildings Automobile service centers Exhibition halls Institutional & Public Buildings Schools & educational campuses Hospitals & healthcare centers Sports complexes & indoor stadiums Auditoriums & community halls Specialized Structures Aircraft hangars Metro & railway sheds Industrial sheds Multi-storey steel buildings Parking structures

Engineered for Enduring Performance

Designed to withstand harsh environmental conditions, including winds up to 150 km/h and earthquakes up to Zone IV, our shopping complexes provide long-lasting durability. The steel structural system and insulated panels promote safety and resilience, while waterproof detailing prevents leaks and dampness. These complexes offer peace of mind, longevity (15-20 years), and low maintenance, making them ideal for urban and rural deployment alike.

Comfort, Safety, and Customization

Beyond robust construction, our modular complexes prioritize comfort with forced ventilation, LED energy-saving lighting, and effective sound insulation (up to 28 dB reduction). Customers and tenants benefit from cool, well-lit interiors and quiet operation. Choose from customizable sizes, layouts, and colors for a shopping environment that matches your vision. Floors are thoughtfully finished with anti-skid ceramic tiles for safety.

FAQ's of Pre fabricated shopping complex:

Q: How is the pre-fabricated shopping complex assembled and how long does it take?

A: The complex is assembled using pre-engineered modular steel frames, wall panels, and roofing sheets, all connected with bolted and welded joints. Depending on the project scale, assembly is generally completed in 2-4 weeks on-site.

Q: What benefits do the wind and fire resistance features offer?

A: Wind resistance up to 150 km/h and fire-rated wall panels provide essential safety, ensuring the complex remains structurally stable and compliant with safety regulations, even in adverse weather or emergency conditions.

Q: Where can these modular complexes be installed, and how customizable are they?

A: These shopping complexes can be installed across India, suitable for both urban and rural settings. Sizes, layout, and colors can be customized to cater to specific site requirements and design preferences.

Q: What is the process for relocating or expanding the shopping complex in the future?

A: The modular design supports full relocatability. Simply disassemble the complex at the current location and re-assemble at the new site. Additional modules can be integrated for expansion as your business grows.

Q: How are waterproofing and acoustic insulation incorporated into the structure?

A: Sealed joints and flashings prevent leaks, while insulated sandwich panels (PUF/PIR/EPS) provide both thermal and sound insulation, ensuring a dry and comfortable shopping environment.

Q: What type of foundation is required and what flooring options are available?

A: The base typically uses pre-cast concrete blocks or an RCC plinth. The flooring comprises anti-skid ceramic tiles over an RCC or steel deck floor, offering safe and durable surfaces capable of supporting up to 300 kg/m2.

Q: What electrical and ventilation provisions are included for commercial tenants?

A: Each unit comes ready for concealed electrical wiring and fittings, with provisions for forced ventilation via exhaust fans to ensure a pleasant and well-ventilated shopping experience.
